Weights
Operating weight with cab and bucket (ISO 6016) 3499 kg
Transport mass (no attachment) 3335 kg
Weight reduction with canopy -118 kg
Additional weight for cab with HVAC 19 kg
Additional weight for steel tracks 96 kg
Additional weight for long dipperstick (with heavy ctw.) 303 kg
Ground pressure with rubber tracks 31.84 kPa
Engine
Make / model Kubota / D1703-M-D1-E4B-BC-2
Fuel Diesel
Number of cylinders 3
Displacement 1642 cm3
Maximum power @ 2200 rpm (ISO 14396) 18.2 kW
Maximum torque (SAE) 97.4 Nm
Performance
Digging force, dipperstick (ISO 6015) 20790 N
Digging force, long dipperstick (ISO 6015) 18010 N
Digging force, bucket (ISO 6015) 33430 N
Drawbar pull 34132 N
Travel speed, low range 2.6 km/h
Travel speed, high range 4.7 km/h
